    Product Details:

    Place of Origin: China
    Brand Name: Rongsheng
    Certification: CE,ISO
    Model Number: RS-1031

    Payment & Shipping Terms:

    Minimum Order Quantity: 5 tons
    Price: 500 USD-10,000 USD
    Packaging Details: in Export Standard Wooden Pallet or Wooden Case
    Delivery Time: 3-5 working days
    Payment Terms: T/T, Western Union, MoneyGram
    Supply Ability: 5000 tons/month
    Contact Now
    Detailed Product Description
    Material: Alumina, Carbon, Zircon Refractoriness (℃): 1770< Refractoriness< 2000
    Shape: Plate MOQ: Negotiable
    Quality: Excellent Type: Refractory Material
    Price: Competitive HS Code: 69022000
    Lead Time: Timely,on Time

    Top quality Slide Gate Plates For Sale, Chinese Manufacturer RS





    Description:

    Import metal or alloy into sliding plate, under middle temperature treatment, forms metal binding phase, and convert non-oxide binding phase when burnt on high temperature condition, therefore improves sliding plate's strength, thermal shock resistance and oxidation resistance, acceptable for different steel ladles, steel making plants.



    Application:
    The slide gate plate is used in the process of steel casting, widely used in large ladle, middle ladle and small ladle.

    Features:
    Excellent thermal shock resistance
    High strength at high temperature,
    Excellent resistance to erosion
    Good resistance to rushing scour.
    Low rough degree after slide surface is used
    Low fissure expansion coefficient



    Physical And Chemical Indicators For High Performance Slide Gate Plate:



    Item RS-HBZ-D RS-HBZ-F1 RS-HBZ-M1 RS-HBZ-F2
    Chemical Composition (%) Al2O3 % 75 80 80 70
    MgO -- -- --
    ZrO2 -- -- -- 5
    C ≤6 ≤6 ≤8 3
    Density(g/cm3) 3.00 3.05 2.95 3.00
    apparent porosity % 10 10 10 11
    compression strength MPa 100 120 100 95



    Physical And Chemical Indicators For High Temperature Firing Slide Gate Plate

    Item RS-HBZ-A RS-HBZ-B RS-HBZ-C RS-HBZ-D
    Chemical Composition (%) Al2O3 % 70 75 75 60
    MgO -- -- 4 --
    ZrO2 -- -- -- 20
    C 4 4 4 4
    Density(g/cm3) 2.85 2.9 3.05 3.00
    apparent porosity % 6(10) 6(10) 6(10) 6(10)
    compression strength MPa 90 100 100 100
