Slide Gate Plates Steel Plants Refractory Excellent Thermal Shock Resistance

Slide Gate Plates Steel Plants Refractory Excellent Thermal Shock Resistance
Slide Gate Plates Steel Plants Refractory Excellent Thermal Shock Resistance Slide Gate Plates Steel Plants Refractory Excellent Thermal Shock Resistance Slide Gate Plates Steel Plants Refractory Excellent Thermal Shock Resistance Slide Gate Plates Steel Plants Refractory Excellent Thermal Shock Resistance Slide Gate Plates Steel Plants Refractory Excellent Thermal Shock Resistance Slide Gate Plates Steel Plants Refractory Excellent Thermal Shock Resistance

Large Image :  Slide Gate Plates Steel Plants Refractory Excellent Thermal Shock Resistance

Product Details:
Place of Origin: China
Brand Name: Rongsheng
Certification: CE,ISO
Model Number: RS-1031
Payment & Shipping Terms:
Minimum Order Quantity: 5 tons
Price: 500 USD-10,000 USD
Packaging Details: in Export Standard Wooden Pallet or Wooden Case
Delivery Time: 3-5 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 5000 tons/month

Slide Gate Plates Steel Plants Refractory Excellent Thermal Shock Resistance

Description
Material: Alumina, Carbon, Zircon Refractoriness (℃): 1770< Refractoriness< 2000
Shape: Plate MOQ: Negotiable
Quality: Excellent Type: Refractory Material
Price: Competitive HS Code: 69022000
Lead Time: Timely,on Time
High Light:

dry pressed Brick

,

Magnesia Carbon Bricks

Top quality Slide Gate Plates For Sale, Chinese Manufacturer RS





Description:

Import metal or alloy into sliding plate, under middle temperature treatment, forms metal binding phase, and convert non-oxide binding phase when burnt on high temperature condition, therefore improves sliding plate's strength, thermal shock resistance and oxidation resistance, acceptable for different steel ladles, steel making plants.



Application:
The slide gate plate is used in the process of steel casting, widely used in large ladle, middle ladle and small ladle.

Features:
Excellent thermal shock resistance
High strength at high temperature,
Excellent resistance to erosion
Good resistance to rushing scour.
Low rough degree after slide surface is used
Low fissure expansion coefficient



Physical And Chemical Indicators For High Performance Slide Gate Plate:



Item RS-HBZ-D RS-HBZ-F1 RS-HBZ-M1 RS-HBZ-F2
Chemical Composition (%) Al2O3 % 75 80 80 70
MgO -- -- --
ZrO2 -- -- -- 5
C ≤6 ≤6 ≤8 3
Density(g/cm3) 3.00 3.05 2.95 3.00
apparent porosity % 10 10 10 11
compression strength MPa 100 120 100 95



Physical And Chemical Indicators For High Temperature Firing Slide Gate Plate

Item RS-HBZ-A RS-HBZ-B RS-HBZ-C RS-HBZ-D
Chemical Composition (%) Al2O3 % 70 75 75 60
MgO -- -- 4 --
ZrO2 -- -- -- 20
C 4 4 4 4
Density(g/cm3) 2.85 2.9 3.05 3.00
apparent porosity % 6(10) 6(10) 6(10) 6(10)
compression strength MPa 90 100 100 100


Slide Gate Plates Steel Plants Refractory Excellent Thermal Shock Resistance 0Slide Gate Plates Steel Plants Refractory Excellent Thermal Shock Resistance 1

Slide Gate Plates Steel Plants Refractory Excellent Thermal Shock Resistance 2
