Product Details:
|
| Material: | Baddeleyite | Color: | White |
|---|---|---|---|
| ZrO2: | 93% | Size: | Customer Requirement |
| Highlight: | insulating firebrick,high temp brick |
||
Specification of Fused Cast High Zirconia
| 1. Al203 | 1% |
| 2. Zro2 | 93% |
| 3. SiO2 | 5% |
| 4. Na2O | 0.5% |
| Baddeleyite | 93% |
| Vitreous Phase | 7% |
| True specific Gravity | 5.3g/cm3 |
| Cold Crushing Strength | 400Mpa |
| Thermal Expansion Rate | 0.3% |
Feature:
ZC-Z95 has excellent corrosion resistance and very low blister and stoning potential. It has no contamination to molten glass nearly .The produce can be mainly used in sidewalls,throats, electrodes and dam of various glass furnaces,especially high quality furnaces and specially glass furnaces.
PRE-ASSEMBLY
After finishing process,the produces will be assemble and checked in partial individual and overall dimensions.Pre-assembly marks,joint marks and other signs(as per customer’s requirements)will be painted on each individual block according to customer requirements
Packing and delivery
Consider various and complex transportation conditions,all fused cast products are packing following the highest standards with foam boards between every two blocks,corners protected with triangular hard cardboards,multi-strengthened by steel bands,wrapping in plastic film on the outside
For easy location of different materials,packing lists are places both inside and outside packages,and shipping marks are clearly painted on all cases.
