High Temperature Resistance Zirconia Mullite Refractory Brick For Glass Furnace

High Temperature Resistance Mullite Insulation Brick Zirconia Mullite Refractory Brick For Glass Furnace

Zirconia mullite brick is made of high-quality bauxite and imported Australian zircon sand, which is melted in an electric arc furnace at a high temperature and cast. zirconia mulite brick compact structure has the advantages of wear resistance, impact resistance, high temperature resistance, good thermal shock resistance, etc., and zirconium mulite brick is mainly applied to parts that require wear resisting and high temperature resistance, such as sliding bricks of metallurgical steel heating furnaces or adopting tapping platforms The tapping platform of the step type heating furnace of the pan and the liner of the garbage incinerator.

Zircon Mullite Brick Description

Zircon mulite firebrick is made of high quality mullite sand and zircon powder as the main material, zircon mulite refractory brick is produced by the production process of molding by high temperature and sintered by high temperature. zirconia mulite firebrick has the characteristics of high bulk density, high strength, good thermal shock resistance, high temperature erosion resistance and good slag resistance. zirconia mulite fire brick is mainly applied to the bottom of the glass kiln pool, paving brick and kiln superstructure.

Properties of Zircon Mullite Brick

.High strength,

.Good slag resistance,

.High bulk density,

.Good thermal shock resistance,

.High temperature erosion resistance.

Manufacturing Process of Zircon Mullite Brick

Zirconium mulite fire brick selectes high quality mullite sand and zircon powder as its main raw material. Molded by high pressure and sintered by high temperature, the zirconium mulite firebrick has such advantages as high bulk density, high strength, good thermal shock resistance, high temperature erosion resistance and good slag resistance. zircon mulite blocks is mainly used in long-life orifice rings, tank bottom, tank superstructure, perfume bottle feeder, covers for working tanks and soda lime glass.

Classification of Zircon Mullite Brick

1. Zirconium fire mullite made of industrial alumina and zircon

2. Zirconium fire mullite made of high alumina bauxite and zircon

3. Fused granules combined with zirconium mullite firebricks

Zircon Mullite Brick Specifications

Item Zirconium Mullite Brick

Zro2(%) 18

Al2o3(%) 55

Sio2(%) 25

Fe2o3(%) 0.5

Apparently Porosity(%) 17

Density Bulk(%) 2.7

Cold Crushing Cold(%) 100

0.2 Mpa refractoriness Under Load(%) 1650

Application of Zircon Mullite Brick

Zircon mulite brick is mainly used in places where wear-resisting and high temperature resistance are required, such as gliding rail bricks in steel pusher metallurgical furnaces, the tapping platform style walking beam furnaces, and also as the interior for destructors. Also zirconium mulite fire brick can be used in the following place:

.Zirconium mulite brick is mainly used in picture tube kiln,

.Zirconium mulite brick is mainly used in large glass kiln melting pools,

.Zirconium mulite brick is mainly used in regenerator partition wall bricks,

.Zirconium mulite brick is mainly used in chemical and metallurgical industrial furnaces.

Zircon Mullite Brick Manufacturer from RS Refractory Factory

RS refractory factory is a professional zircon mulite brick supplier that established in the early 90s of twenty century. RS refractory factory has specialized in zirconia mulite brick for more than 20 years. if you have some demand of zirconium mulite brick, or have some questions on zircon mulite firebrick about physical and chemical indicators, please contact us for free. and Rs refractory factory as a professional zircon mulite refractory brick manufacturer in china, has some competitive advantages as follows:

Competitive Price: Make the products competitive in your market,

Abundant Experience: Prevent cracks and twist in bricks,

Different Moulds: Save mould fees for you,

Strict Quality Control: Meet clients’ quality requirement,

Large stocks: Guarantee prompt delivery,

Professional Packing: Avoid damage and secure the goods in transportation.
