Product Details:
|
| Material: | Ceramic Fiber | Thermal Conductivi: | 0.17 |
|---|---|---|---|
| Working Tem: | 1100 | Temperature Rating: | 1260°C |
| Colour: | White | Thickness: | 25 Mm |
| Tempreture: | 1260 | Working Temperature: | 1260 Degree |
| Fiber Diameter: | 3-5um | Temprature Classification: | 1260℃-1600℃ |
| Tensile Strength: | 0.08 MPa | Density: | 64 Kg/m3 |
| Shape: | Ceramic Fiber Blanket | Weight: | 14kg |
| Flame Resistance: | Non-flammable | ||
| Highlight: | 1400c refractory sealing strip,1260c refractory sealing strip,3mm refractory sealing strip |
||
Standard size:
60000x610x1mm / 30000x610x2mm / 20000x610x3mm / 15000x610x4mm / 12000x610x5mm / 10000x610x6mm
Specifications of ceramic fiber paper:
| Type | Standard ceramic fiber paper | High pure ceramic fiber paper | High Aluminium ceramic fiber paper | Zirconium ceramic fiber paper | |
| Chemical analysis (%) | AL2O3 | 43 | 47 | 55 | 38 |
| SiO2 | 53 | 51 | 44 | 44 | |
| Fe2O3+Ti2O3 | ≤1.2 | ≤0.3 | ≤0.3 | ≤0.2 | |
| CaO+MgO | ≤0.3 | ≤0.3 | ≤0.3 | ≤0.2 | |
| NaO+K2O | ≤0.5 | ≤0.3 | ≤0.3 | ≤0.2 | |
| Crganic Content (%) | 5% | ≤5% | ≤5% | ≤5% | |
| Density(kg/m3) | 180-220 | 180-220 | 180-220 | 180-220 | |
| Work Temperature | 1050 | 1150 | 1250 | 1350 | |
| Thickness | 0.5-12mm | ||||
| size (mm) | 40000x1220x1;40000x610x1; 30000x1220x2; 30000x610x2;20000x1220x3;20000x610x3;15000x610x4; 10000x610x5 | ||||
Application of ceramic fiber paper:
1:Industrial insulation, sealing, anti-corrosion material
2:Insulation material for instruments and heating element
3:Insulation material for automobile and aerospace industry
4:Expansion joints filling material
5:Isolation for construction material, metallurgy and glass industries,
6:Molten metal sealing gasket
7:Fireproof material
8:Substitute for glass fiber and asbestos fiber
