1400 Kaowool Ceramic Felt 128 Kg/M3 High Aluminum Silicate Ceramic Fiber Blanket Heat Insulation For Industrial Furnaces

Large Image : 1400 Kaowool Ceramic Felt 128 Kg/M3 High Aluminum Silicate Ceramic Fiber Blanket Heat Insulation For Industrial Furnaces

Product Details:

Place of Origin:	Henan, China
Brand Name:	RONGSHENG
Certification:	ISO9001

Contact Now

1400 Kaowool Ceramic Felt 128 Kg/M3 High Aluminum Silicate Ceramic Fiber Blanket Heat Insulation For Industrial Furnaces

Description

Color:	White To Off-white	Flexibility:	High
Fiber Diameter:	3-5	Working Temperature:	1260-1430C
Packing:	Inside Plasric Bag	Bulk Density:	64/96/128/160kg/m3
Oem Odm:	YES	Compressive Strength:	0.05 MPa
Service Temperature:	1000-1300 Degree	Alkali Resistance:	Good
Apparent Porosity:	18	Refractoriness:	1050-1800C
Colour:	White	Density:	128-320 Kg/m³
Efractoriness:	1790
Highlight:	1400 Kaowool ceramic fiber blanket , high aluminum silicate insulation blanket , industrial furnace heat insulation blanket

Features of Ceramic Fiber blanket:

1. High heat oven insulation blanket is made of high quality alumina-silicate ceramic fiber by using double side needling methods which improve the tensile strength and the flatness of the ceramic fiber blanket.
2. High heat oven insulation blanket contains no organic binders which guarantee the stability and constructability of the ceramic fiber blanket at both high temperature and low temperature.
3.Temperature: Rated to 2400℉.Our products have high heat insulation efficiency and light weight, which are the ideal choice for your heat insulation needs.
4.Ultra-high density: 128 Kg/ M3, fine and soft texture, make our insulation blanket your best choice!

1400 Kaowool Ceramic Felt 128 Kg/M3 High Aluminum Silicate Ceramic Fiber Blanket Heat Insulation For Industrial Furnaces

Application

Industry	Applications
Ceramic industry	Kiln car insulation and seals, Continuous and batch kilns
Steel industry	Heat treating and annealing furnaces, Furnace door linings and seals, Soaking pit covers and seals, Furnace hot face repairs, Reheating furnace and ladle covers,
Refining and petrochemical industry	Reformer and pyrolysis lining, Tube seals,gaskets and expansion joints, High temperature pipe,duct and turbine insulation Crude oil heater linings
Power generation industry	Boiler insulation,Boiler doors,Reusable turbine covers, Expansion seals/pipe coverings
Other	Insulation of commercial dryers and ovens Veneer over existing refractory Stress relieving insulation Glass furnace crown protection Fire protection

1400 Kaowool Ceramic Felt 128 Kg/M3 High Aluminum Silicate Ceramic Fiber Blanket Heat Insulation For Industrial Furnaces

Send us inquiry to get more information !!!

Specification

Ceramic Fiber Insulation Blanket Specification

Type	1260 Blanket	1400 Blanket	1500 Blanket	1600 Blanket
Classification temperature ( °C)	1260	1425	1500	1600
Melting point (°C)	1760	1700	1760	-
Colour	White	White	Blue gree	White
Fiber diameter ( u m)	2.6	2.8	2.65	3.1
Fiber length (mm)	~250	~250	~150	~100
Linear shrinkage(%)	(1100oC x 24 hrs)1.8	(1300 o C x 24 hrs) 1.5	-	-
Shot content (>212 micro meter) (%)	18	18	-	-

Thermal conductivity Kcal/mh °C (W/mK) ,ASTM C201
1260 blanket	64 kg/m3	96 kg/m3	128 kg/m3	160kg/m3
mean 400°C	0.13	0.12	0.07	0.09
mean 600 °C	0.21	0.17	0.12	0.14
mean 800°C	0.30	0.25	0.16	0.20
1400 blanket	-	-	128 kg/m3	160kg/m3
mean 600 °C	-	-	0.13	0.14
mean 800 °C	-	-	0.20	0.20
mean1000 °C	-	-	0.29	0.28

Chemical composition (%)
	1260 Blanket	1400 Blanket	1500 Blanket	1600 Blanket
Al2O3	47.1	35.0	40.0	72
SiO2	52.3	49.7	58.1	28
ZrO2	-	15.0	-	-
Cr2O3	-	-	1.8	-
Bulk density(Kg/m3)	64,96,128,160
Available size(mm/roll)	72006006,12.5,20,25,38;360060050

Standard ceramic fiber blanket - working temperature 1050 ℃
High-alumina ceramic fiber blanket - working temperature 1260 ℃
Zirconia ceramic fiber blanket - working temperature 1350 ℃
Bulk density:64 kg/m3,96 kg/m3,128 kg/m3,160kg/m3
