Product Details:
|
| Bulk Density: | 180-200kg/m3 | Temprature Classification: | 1260℃-1600℃ |
|---|---|---|---|
| Package: | Braided Bag/carton | Type: | High Purity High Working Temperature |
| Tempreture: | 1260 | Width: | 610 Mm |
| Temperature: | 1260C | Chemical Content: | Al2O3+SiO2 |
| Colour: | White | Usage: | Industrial, Commercial, Residential |
| Working Tem: | 1000 | Working Temperature: | 1200 Degree |
| Length: | 7200 Mm | Application: | Insulation And Heat Protection |
| Chemical Composition: | Al2O3-SiO2 | ||
| Highlight: | 0.3-15mm ceramic fiber paper,1260 thermal insulation ceramic fiber paper,1260 ceramic fiber paper |
||
0.3-15mm thickness aluminum silicate fiber paper 1260 thermal insulation ceramic fiber paper
Ceramic Fiber Paper(ceramic fiber wool paper gasket) is processed from the high purity fiber, which can be used in the field of high temperature insulation. Because we have adopted the advanced processing work, we cannot only make the fiber interweave shapely, but also can control the thickness and the density rigidly.
We can produce Standard ceramic fiber paper,High pure ceramic fiber paper,High Aluminium ceramic fiber paper,Zirconium ceramic fiber paper,the use of temperature can reach 1350C, and have excellent eco-friendly performance.
Characteristics of ceramic fiber paper:
1:Low thermal capacity
2:Low thermal conductivity
3: Excellent electrical insulation properties
4:Excellent machining performance
5: High strength, tear resistance
6: High flexibility
7:Low slag content
8:Excellent fire proof property
Standard size:
60000x610x1mm / 30000x610x2mm / 20000x610x3mm / 15000x610x4mm / 12000x610x5mm / 10000x610x6mm
Specifications of ceramic fiber paper:
| Type | Standard ceramic fiber paper | High pure ceramic fiber paper | High Aluminium ceramic fiber paper | Zirconium ceramic fiber paper | |
| Chemical analysis (%) | AL2O3 | 43 | 47 | 55 | 38 |
| SiO2 | 53 | 51 | 44 | 44 | |
| Fe2O3+Ti2O3 | ≤1.2 | ≤0.3 | ≤0.3 | ≤0.2 | |
| CaO+MgO | ≤0.3 | ≤0.3 | ≤0.3 | ≤0.2 | |
| NaO+K2O | ≤0.5 | ≤0.3 | ≤0.3 | ≤0.2 | |
| Crganic Content (%) | 5% | ≤5% | ≤5% | ≤5% | |
| Density(kg/m3) | 180-220 | 180-220 | 180-220 | 180-220 | |
| Work Temperature | 1050 | 1150 | 1250 | 1350 | |
| Thickness | 0.5-12mm | ||||
| size (mm) | 40000x1220x1;40000x610x1; 30000x1220x2; 30000x610x2;20000x1220x3;20000x610x3;15000x610x4; 10000x610x5 |
||||
