High Temperature Furnace Aluminum Silicate Insulation Board 1800C Refractory Ceramic Fiber Board

$High Temperature Furnace Aluminum Silicate Insulation Board 1800C Refractory Ceramic Fiber Board$

$High Temperature Furnace Aluminum Silicate Insulation Board 1800C Refractory Ceramic Fiber Board$

Large Image : High Temperature Furnace Aluminum Silicate Insulation Board 1800C Refractory Ceramic Fiber Board

Product Details:

Place of Origin:	Henan, China
Brand Name:	RONGSHENG
Certification:	ISO9001

Contact Now

High Temperature Furnace Aluminum Silicate Insulation Board 1800C Refractory Ceramic Fiber Board

Description

Compressive Strength:	0.08 MPa	Tempreture:	1260
Weight:	14kg	Temprature Classification:	1260℃-1600℃
Thermal Conductivity:	0.045 W/m·K	Length:	7200 Mm
Grade:	COM (Common)	Working Temperature:	1000-1100
Chemical Composition:	Al2O3-SiO2	Color:	White
Shape:	Blanket Or Board	Chemical Resistance:	Excellent
Tensile Strength:	0.04 MPa	Flexibility:	Flexible
Fiber Diameter:	3-5
Highlight:	Aluminum Silicate Insulation Board , 1800C Refractory Ceramic Fiber Board , High Temperature Furnace Ceramic Fiber Board

Ceramic fiber board is made of high purity ceramic fiber by adding some binders. Ceramic fiber is a new type of insulating material which contains no asbestos, is eco-friendly and has no cancer-producing effect. Ceramic Fiber Board is made through automation control and continuous production process.

Except all the advantage of ceramic fiber bulk it has many other merits, such as solid texture, wind erosion resistance, excellent tenacity etc. It is an ideal material for building tunnels, furnace and many other insulating types of equipment.

Ceramic Fiber Board Features:


♦ Non-combustible,1100°C< Refractoriness< 1430°C ♦ Low density and low thermal conductivity ♦ Shorter heat up and cool down time ♦ Resilience and resistance to thermal shock ♦ Flexible and easy to cut or install ♦ Contain no organic binder ♦ Asbestos free

$High Temperature Furnace Aluminum Silicate Insulation Board 1800C Refractory Ceramic Fiber Board 0$

Ceramic Fiber Board Specification

Standard ceramic fiber board

High aluminum ceramic fiber board

zirconia ceramic fiber board

$High Temperature Furnace Aluminum Silicate Insulation Board 1800C Refractory Ceramic Fiber Board 1$

$High Temperature Furnace Aluminum Silicate Insulation Board 1800C Refractory Ceramic Fiber Board 2$

$High Temperature Furnace Aluminum Silicate Insulation Board 1800C Refractory Ceramic Fiber Board 3$

Working Temperature 1260℃

Working Temperature 1360℃

Working Temperature 1430℃

Product Advantage

Ceramic Fiber Board Advantage:

Competitive Price. Make the products competitive in your market. Abundant Experience. Prevent cracks and twist in bricks. Different Moulds. Save mould fees for you. Strict Quality Control. Meet clients’ quality requirement. Large stocks. Guarantee prompt delivery. Professional Packing. Avoid damage and secure the goods in transportation

$High Temperature Furnace Aluminum Silicate Insulation Board 1800C Refractory Ceramic Fiber Board 4$

Specification

Type		common	standard	high pure	high aluminum	zircon
classfication Temperature(℃)		1100	1260	1260	1360	1430
Working Temperature(℃)		≤1000	1050	1100	1200	1350
color		white	pure white	pure white	pure white	pure white
Shrinkage on heating (%)(Temperature 24 hours, density as 320kg/m3)		-4 (1000°C)	-3 (1000°C)	-3 (1100°C)	-3 (1200°C)	-3 (1350°C)
Thermal conductivity of various temperatures (w/m.k) (density 285kg/m3)		0.085 (400°C) 0.132 (800°C) 0.180 (1000°C)	0.085 (400°C) 0.132 (800°C) 0.180 (1000°C)	0.085 (400°C) 0.132 (800°C) 0.180 (1000°C)	0.085 (400°C) 0.132 (800°C) 0.180 (1000°C)	0.085 (400°C) 0.132 (800°C) 0.180 (1000°C)
Compressive strength (Mpa)		0.5	0.5	0.5	0.5	0.5
Chemical composition (%)	AL2O3	44	46	47-49	52-55	39-40
	AL2O3+SIO2	96	97	99	99	-
	AL2O3+SIO2+ZrO2	-	-	-	-	99
	ZrO2	-	-	-	-	15-17
	Fe2O3	<1.2	<1.0	0.2	0.2	0.2
	Na2O+K2O	<0.5	<0.5	0.2	0.2	0.2
Dimensions (mm)	Common Specifications: 60040010-50; 90060010-50 120050010-50; 1200100010-50; 100060010-50 Other specifications can be available.

Product Application

$High Temperature Furnace Aluminum Silicate Insulation Board 1800C Refractory Ceramic Fiber Board 5$
