Furnace Kiln Boiler Refractory Materials Ceramic Fibre Board 1260C 1430C Aluminum Silicate Insulation Boards

$Furnace Kiln Boiler Refractory Materials Ceramic Fibre Board 1260C 1430C Aluminum Silicate Insulation Boards$

$Furnace Kiln Boiler Refractory Materials Ceramic Fibre Board 1260C 1430C Aluminum Silicate Insulation Boards$

Large Image : Furnace Kiln Boiler Refractory Materials Ceramic Fibre Board 1260C 1430C Aluminum Silicate Insulation Boards

Product Details:

Place of Origin:	Henan, China
Brand Name:	RONGSHENG
Certification:	ISO9001

Contact Now

Furnace Kiln Boiler Refractory Materials Ceramic Fibre Board 1260C 1430C Aluminum Silicate Insulation Boards

Description

Refractory Temperature:	1260℃	Color:	White To Off-white
Grade:	COM (Common)	Apparent Porosity:	18
Thermal Conductivity:	0.055-0.180(W.k.m.)	Fiber Diameter:	20mm 30mm 50mm
Thermalconductivity:	0.11 To 0.16 W/m·K	Installation:	Easy To Cut And Install
Fire Resistance:	Non-combustible	Width:	610mm To 1220mm
Chemical Resistance:	Excellent	Oem Odm:	YES
Size:	Customizable	Chemical Composition:	AL2O3
Chemicalresistance:	Good Resistance To Most Chemicals

Ceramic Fiber Board Advantage:


1, with high temperature thermal conductivity, light weight, long life, tensile strength, good elasticity, non-toxic and so on.

2, high compressive strength, long service life;

3, low heat capacity, low thermal conductivity;

4, non-brittle material, good toughness;

5, the size of accurate, good flatness;

6, easy to install,

7, excellent anti-wind erosion performance;

8, continuous production, fiber distribution, performance and stability;

9, excellent sound and noise reduction performance.

$Furnace Kiln Boiler Refractory Materials Ceramic Fibre Board 1260C 1430C Aluminum Silicate Insulation Boards 0$

Specification

Type		COM	ST	HP	HA	Zir-Alu	HZ
Classified Temp.		1100ºC (1983ºF)	1260ºC (2300ºF)	1260ºC (2300ºF)	1360ºC (2480ºF)	1400ºC (2550ºF)	1430ºC (2600ºF)
Working Temp.		<1000ºC (2012ºF)	1050ºC (1922ºF)	1100ºC (2012ºF)	1200ºC (2192ºF)	1200ºC (1192ºF)	1350ºC (2462ºF)
Color		white	white	white	white	white	white
Density(kg/m3)		260-320 (16-20lb/ft3)	260-320 (16-20lb/ft3)	260-320 (16-20lb/ft3)	260-320 (16-20lb/ft3)	260-320 (16-20lb/ft3)	260-320 (16-20lb/ft3)
Linear Shrinkage (%) (24 hrs)		-3 (1000ºC/1832ºF)	-3 (1000ºC/1832ºF)	-3 (1100ºC/2012ºF)	-3 (1250ºC/2282ºF)	-3 (1000ºC/2012ºF)	-3 (1350ºC/2462ºF)
Thermal conductivity (W/M.K)		0.085 (400ºC/752ºF) 0.132 (800ºC/1472ºF) 0.180 (1000ºC/2012ºF)	0.085 (400ºC/752ºF) 0.132 (800ºC/1472ºF) 0.180 (1000ºC/2012ºF)	0.085 (400ºC/752ºF) 0.132 (800ºC/1472ºF) 0.180 (1000ºC/2012ºF)	0.085 (400ºC/752ºF) 0.132 (800ºC/1472ºF) 0.180 (1000ºC/2012ºF)	0.085 (400ºC/752ºF) 0.132 (800ºC/1472ºF) 0.180 (1000ºC/2012ºF)	0.085 (400ºC/752ºF) 0.132 (800ºC/1472ºF) 0.180 (1000ºC/2012ºF)
Compression Strength (Mpa)		0.5	0.5	0.5	0.5	0.5	0.5
Chemical(%)	Al2O3	44	46	47-49	52-55	45-46	39-40
	Al2O3+SiO2	96	97	99	99	-	-
	Al2O3+SiO2+ZrO2	-	-	-	-		99
	ZrO2	-	-	-	-	.5-7	15-17
	Fe2O3	<1.2	<1.0	0.2	0.2	0.2	0.2
	Na2O+K2O	≤0.5	≤0.5	0.2	0.2	0.2	0.2
Size(mm)		12001000mm(47″40″); 1000600mm(40″36″);900600mm(24″36″) 20-50mm(1″/2″)thickness

$Furnace Kiln Boiler Refractory Materials Ceramic Fibre Board 1260C 1430C Aluminum Silicate Insulation Boards 1$

Product Application

Fire resistant ceramic fiber board applications:


1.Industrial kiln wall lining, masonry insulation layer, high temperature, high heat equipment insulation, insulation, high temperature kiln kiln lining, kiln car, door baffle, furnace furnace temperature divider, aerospace, shipbuilding insulation, Fireproof, soundproof, insulated. 2.Iron and steel industry: expansion joints, insulation, insulation and insulation; non-ferrous metal industry: backing insulation materials, tundish and tank cover for pouring copper and copper alloy; 3.Ceramic industry: light kiln car structure and the furnace hot surface lining, the furnace temperature zone separation and fire materials; Glass industry: the pool was lining heat, burner block; 4.Furnace building: hot surface refractories (alternative fiber blanket), heavy refractory lining, expansion joints; 5.Light industry: lining of industrial and domestic boiler combustors; 6.Petrochemical industry: high temperature heating furnace lining hot surface material; 7.Building materials industry: cement rotary kiln and other equipment insulation.
